FuseBox Doorbell Transformer 8V 1A

Description

This FuseBox Doorbell Transformer is suitable for installation in FuseBox consumer units and non-combustible enclosures. The bell transformer is used to provide power to a standard mains-powered doorbell, lowering the voltage from 230V to 8-24V.

Key Features

• Ideal for installation in FuseBox consumer units
• Suitable for standard doorbells
• This transformer is double insulated
• Standard DIN rail mounted
• 1A resisitive, 4A inductive
• 2 module

Technical Information

• Maximum Load: 8V/1A, 12V/0.67A, 24V/0.33A
• Terminal Capacity: 4mm² / 1.5Nm
• Material: PA66 Nylon
• Frequency: 50Hz
• Weight: 0.43kg
• Height: 86mm
• Voltage: 230V
• Depth: 68mm
• Width: 35.5

Approvals

• BS EN 61558-2-8
• EN 61558-1
