Description
This Q-Nect IP68 Nylon Cable Gland has a 20mm threaded diameter and accepts 8-12mm cables. It protects electrical installations and provides a waterproof entry point into electrical enclosures like junction boxes and consumer units. The 20mm cable gland is made of nylon and comes in an anthracite grey colour.
Key Features
- Has a 20mm threaded diameter, and a 10mm threaded entry length
- Protects cables from moisture, dust, cable fatigue and strain
- IP68 rated to create waterproof cable entry points
- Compatible with 8-12mm diameter cables
- Made with a strong and long-lasting seal
Technical Information
- Operational Temperature Range: 0 to +80°C
- Gland Materials: Nylon 66, TPE and PVC
- Tightening Torque Range: 2-2.5Nm
- Cable Clamping Range: 8-12mm
- Threaded Diameter Size: 20mm
- Threaded Entry Length: 10mm
- Required Spanner Size: 24mm
- Colour: Anthracite Grey
- Pack Size: 1 Piece
- Brand: Unicrimp
- IP Rating: IP68
Approvals
- BS EN 60529: 1992 + A2:2013
- ANSI/UL 514B
- BS 6121
If you’d like to learn more about IP ratings, see our IP Ratings guide page.
